MH Eco3 helical hot air gas unit heater

Compact and aesthetic heating solution by direct blowing suitable for buildings:

of low height
industrial
shops
tertiary
well insulated
new or for renovation

Avantages

High combustion efficiency 93%
Weldless exchanger in 2 mm thick aluminised steel
Low height appliances
Simple to use and maintain
Compact and aesthetic
Low temperature blowing
Double Deflection Grille
Silent running
Respects the environment with its low NOx level
Time-saving installation using “bus” pilot wire for regulation
2-stage burner

Details techniques

Description Paramètres Téléchargements Références Demander un devis

Description

5 models from 26 to 80 kW
Multi-torch burner
4-channel horizontal tubular exchanger
2 mm thick weldless tubular exchanger in aluminised steel
Motorised fan unit 900 rpm with crescent-shaped blades (mounted on anti-vibration pads)
Aluminium tinted front diffuser with adjustable vertical
and horizontal vents
2-stage solenoid valve
Automatic ignition by electrode
Ionisation probe flame control
Case in sheet steel with oven-baked epoxy paint RAL 9010
Remote resetting with control unit
